BUTTERFLY VALVES
Our company is a best manufacturer and supplier of Butterfly Valves in India made from optimum quality raw material. These valves are manufactured to have optimal mix structural stability, flow efficiency and effective seating coupled with advantage of light weight, compact design and ease of operation. These Valves are highly valued for isolating and regulating flow in the pipe lines. Clients can avail these Industrial Butterfly Valves at rock bottom prices.
Our Butterfly Valve is mostly used in concrete pumps as well as oil industries for different applications. As the valve has powerful structure, it is suitable to control or block the flow of fluid or other substances effectively. These valves are rigorously tested by our quality experts before supplying to the clients at stipulated timeframe.
FEATURES OF BUTTERFLY VALVE :
- Valve Suitable For Maximum Temperature 80oc
- User Friendly
- Highly durable
- Compact & Simple Design
- Low Maintenance Cost
- Available In Customized Range
- Corrosion-Resistance
Other Material Available on Special Request
- Tempreature range - 20 to 180°c
- Pressure range PN 10 & PN 16
- Face to face distance : as per ISO 5752 wafer short / API 609
- Suitable for mounting between flages to ANSI, PIN and BS 10 tables D. E. & F or BS 4504 PN 10 / 16, Tables 6,7 & 8 of IS: 6418 and Table 11, 15 & 17 of IS 6392
- "Flowrise" lined seal valves can also be supplied with gear Unit, Pneumatic/ Electric actuator extension spindle, Chain wheel arragement etc. on request.
Item |
Part |
Material Options |
1. |
Body |
Castr Iron I. S. 210 Grade FG200/GG 25; Ductile cast iron GGG 40; Cast carbon steel ASTM A- 216 Grade WCB; Cast stainless steels CFB & CF8M |
2. |
Disc |
Cast iron I. S. 210 grade FG200/ GG25; Ductile cast iron GGG40; Cast carbon steel ASTM A - 216 Grade WCB; Cast stainless steels CFB & CF8M |
3. |
Seat |
Nitrile, EPDM, Viton, Silicone |
4. |
Shaft |
AISI 410/316 |
5. |
Bearing |
Steel/PTFE |
6. |
O-ring |
Nitrile, EPDM, Viton, Silicone |
7. |
Taper pin |
AISI 410/316 |
8. |
Plug |
Steel |
9. |
Bush |
Polyacetal |
|
DN mm |
A |
B |
C |
D |
Weight mm |
50 |
50 |
43 |
74 |
113 |
6 |
65 |
65 |
46 |
81 |
121 |
7 |
80 |
80 |
46 |
89 |
128 |
8 |
100 |
100 |
52 |
105 |
146 |
11 |
125 |
125 |
56 |
117 |
158 |
15 |
150 |
150 |
56 |
140 |
174 |
16 |
200 |
200 |
60 |
165 |
198 |
26 |
250 |
250 |
68 |
205 |
245 |
40 |
300 |
300 |
78 |
230 |
270 |
52 |
350 |
336 |
78 |
255 |
288 |
56 |
400 |
386 |
102 |
310 |
350 |
77 |
450 |
436 |
114 |
335 |
380 |
94 |
500 |
486 |
127 |
370 |
410 |
120 |
600 |
586 |
154 |
420 |
490 |
152 |
|
